Curb Pouring Machine--HT400

2022 Newest Factory Hot Sale Automatic Kerb Casting Slipform Paver Slipform Machine For Curbs

2022 Newest Factory Hot Sale Automatic Kerb Casting Slipform Paver Slipform Machine For Curbs

Brand Name:HT
Model Number: HT400
Certification: ISO
Start-up Mode: Electric Start
INQUIRY BUY NOW

Slipform Road Curb Paver, Small Road Paver Machine:

Application And Features:

The Kerb Casting Slipform Paver Slipform Machine eliminates multiple processes such as pre-setting, transportation to the site and re-installation, which reduces the construction cost and improves the construction quality and construction speed. The function of the Kerb Casting Slipform Paver Slipform Machine we produce is further improved to meet different road conditions, and can produce various specifications and models of curb stones.

Technical Parameters:

HT400	Specifications		Features
Dimension	2400mmx1700mmx1100mm		Compact, easy to move
Weight	1100kg
Road Kurb Size range	Width≤600mm,height≤450mm		Is Widely applicable for kurbs
Parameters Of engine set	Fuel	Diesel	Single-cylinder water-cooled diesel engine, simple and reliable
	Power	8kw
	Output voltage	380v,3 phases
	Start-up mode	Electric start
	Radiating way	Water cooling
The curbs molding way	Vibrator rod forming	Dry plastic concrete	High strength
The curbs molding way	Flat vibrator forming	Dry hard concrete	Beautiful appearance
Paving speed	1-4m/min		Imported CVT (Continuously Variable Transmission), facilitate the adjustment of the most suitable paving
