Curb Pouring Machine--HT400

  • 2022 New Designed Kerbstone Brick Making Machine
  • 2022 New Designed Kerbstone Brick Making Machine
  • 2022 New Designed Kerbstone Brick Making Machine
  • 2022 New Designed Kerbstone Brick Making Machine
2022 New Designed Kerbstone Brick Making Machine2022 New Designed Kerbstone Brick Making Machine2022 New Designed Kerbstone Brick Making Machine2022 New Designed Kerbstone Brick Making Machine

2022 New Designed Kerbstone Brick Making Machine

  • Brand Name:HT
  • Model Number: HT400
  • Certification: ISO
  • Start-up Mode: Electric Start
  • INQUIRY BUY NOW

Kerbstone Brick Making Machine, Kerbstone Brick Machine:

Application And Features:

The Kerbstone Brick Making Machine is used for road shoulder sliding film action, drainage ditch sliding film operation, curb forming operation, etc. This type of machine is the carrier of engineering standards, including asphalt products and cement concrete road construction projects The industrial equipment for the curbs and drainage ditches on both sides of the center is composed of a walking mechanism, a vibration mechanism, a forming mechanism, a generator and a power distribution.

Technical Parameters:

HT400

Specifications

Features

Dimension

2400mmx1700mmx1100mm

Compact, easy to move

Weight

1100kg

Road Kurb Size range

Width≤600mm,height≤450mm

Is Widely applicable for kurbs

Parameters

Of engine set

Fuel

Diesel

Single-cylinder water-cooled diesel engine, simple and reliable

Power

8kw

Output voltage

380v,3 phases

Start-up mode

Electric start

Radiating way

Water cooling

The curbs molding way

Vibrator rod forming

Dry plastic concrete

High strength

Flat vibrator forming

Dry hard concrete

Beautiful appearance

Paving speed

1-4m/min

Imported CVT (Continuously Variable Transmission), facilitate the adjustment of the most suitable paving


Kerbstone Brick Making Machine Physical picture:





Kerbstone Brick Making Machine drawing





Kerbstone Brick Making Machine Packaging diagram :
